HDM3S400M40033XX - Molded case circuit breaker, HDM3S, 400M, 400A 3P, TM, adjustable, 40℃ - 1

HDM3S400M40033XX - Molded case circuit breaker, HDM3S, 400M, 400A 3P, TM, adjustable, 40℃

Ürün Kodu : HDM3S400M40033XX
5.788,54 ₺ / 5.788,54 TL + KDV
 tarihine kadar kargoda
kargo bedava
güvenli alışveriş
vade farksız taksit
ücretsiz iade
Açıklamalar
Main
Range of product HDM3S
Product or component type Enclosed moulded case circuit breaker
Frame size 400AF
Suitability for isolation Yes
Trip unit technology Thermal-magnetic
Device application Power distribution protection
Voltage release type Shunt trip releaseUndervoltage release
Provided equipment alarmmotor mechanismhandleterminal extensioninterphase barriersMN or MX voltage release
Poles description 3P
[In] rated current 400 A
[Ue] rated operational voltage 400/415 V
Network type AC
Network frequency 50/60 Hz
Electrical durability 1000 cycles
Mechanical durability 4000 cycles
[Uimp] rated impulse withstand voltage 8.0 kV
[Ics] rated service breaking capacity 50 kA at 400 V
Rated breaking capacity 50 kA at 400 V
[Ui] rated insulation voltage 1000 V
Clamping connection capacity 240 mm²
Utilisation category Category A
Height 257 mm
Width 140 mm
Depth 155 mm
IP degree of protection IP20
Installation category III
Pollution degree 3
Ambient air temperature for operation -5…40 °C
Ambient air temperature for storage -20…70 °C
Operating altitude 0...2000 m
Standards IEC 60947-2
Product certifications TÜV
Unit Type of Package 1 PCE
Number of Units in Package 1 1
