HJX2F3304M7 - Contactor, HJX2F-330, 4P, 4NO, 220/230 V, 50/60 Hz - 1
HJX2F3304M7 - Contactor, HJX2F-330, 4P, 4NO, 220/230 V, 50/60 Hz - 2
HJX2F3304M7 - Contactor, HJX2F-330, 4P, 4NO, 220/230 V, 50/60 Hz - 3

HJX2F3304M7 - Contactor, HJX2F-330, 4P, 4NO, 220/230 V, 50/60 Hz

Ürün Kodu : HJX2F3304M7
14.286,10 ₺ / 14.286,10 TL + KDV
 tarihine kadar kargoda
kargo bedava
güvenli alışveriş
vade farksız taksit
ücretsiz iade
Açıklamalar
Main
Range of product HJX2F 4P
Product or component type Contactor
Contactor application Non-reversing
Poles description 4P
[Uc] control circuit voltage 220/230 V AC 50/60 Hz
Mechanical interlocking Without mechanical interlock
[In] rated current 330 A
Auxiliary contact composition 4 NO
[Ui] rated insulation voltage 690 V
[Uimp] rated impulse withstand voltage 8 kV
[Ie] rated operational current 330 A at 440 V AC-3117 A at 440 V AC-3235 A at 660 V AC-4107 A at 660 V AC-4
Motor power kW 100 kW at 220/240 V AC 50/60 Hz AC-3 for 3 phases motors160 kW at 380/400 V AC 50/60 Hz AC-3180 kW at 415 V AC 50/60 Hz AC-3180 kW at 440 V AC 50/60 Hz AC-3200 kW at 500 V AC 50/60 Hz AC-3220 kW at 660/690 V AC 50/60 Hz AC-3160 kW at 1000 V AC 50/60 Hz AC-3
[Ith] conventional free air thermal current 400 A
Installation category III
Pollution degree 3
Ambient air temperature for operation -5…40 °C
Average ambient air temperature for operation <= 35 °C (average over 24 hours)
Ambient air temperature for storage -25…55 °C
Operating altitude 2000 m
Standards EN/IEC 60947-4-1
Product certifications CE
IP degree of protection IP20
Relative humidity 0…90 %
Unit Type of Package 1 PCE
Number of Units in Package 1 1
