General ordering data
| Version | CableLine, Conductor and cable markers, 2.5 - 5 mm, 3 x 4.2 mm, yellow |
| Order No. | 0252611502 |
| Type | CLI C 1-3 GE/SW 0 MP |
| GTIN (EAN) | 4008190052607 |
| Qty. | 200 pc(s). |
Dimensions and weights
| Depth | 5 mm |
| Depth (inches) | 0.197 inch |
| Height | 3 mm |
| Height (inches) | 0.118 inch |
| Width | 4.2 mm |
| Width (inches) | 0.165 inch |
| Net weight | 0.055 g |
Temperatures
| Operating temperature range | -30...80 °C |
Environmental Product Compliance
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
General data
| Colour | yellow |
| Colour of printing | black |
| Halogen | Yes |
| Insulation cross-section, max. | 5 |
| Material | PVC, soft, without Cadmium |
| Material colour according to resistance code | 4 |
| Number of markers per combination | 1 Component part = Conductor and cable markers |
| Number of markers per packaging unit | | Form of supply | Component part | | |
| Operating temperature range | -30...80 °C |
| Operating temperature range, max. | 80 °C |
| Operating temperature range, min. | -30 °C |
| Orientation of print | horizontal |
| Printed characters | Numbers |
| Printing | 0 |
| Printing method | hot-embossing |
| Recommended industries | Process, Machinery |
| Type of printing | Standard |
| UL 94 flammability rating | V-0 |
| Version | MultiPack |
| Width | 4.2 mm |
Conductor and cable markers
| Conductor O.D. | 2.5 - 5 mm |
| Conductor O.D., max. | 5 mm |
| Conductor O.D., min. | 2.5 mm |
| Conductor cross-section, max. | 4 mm² |
| Conductor cross-section, min. | 1.5 mm² |
| Cross-section for connected wire | 1.5 - 4 mm² |
| Halogen | Yes |
Downloads
Classifications
| ETIM 6.0 | EC001530 |
| ETIM 7.0 | EC001530 |
| ETIM 8.0 | EC001530 |
| ETIM 9.0 | EC001530 |
| ECLASS 9.0 | 27-40-04-01 |
| ECLASS 9.1 | 27-40-04-01 |
| ECLASS 10.0 | 27-40-04-01 |
| ECLASS 11.0 | 27-28-11-02 |
| ECLASS 12.0 | 27-28-11-02 |
| ECLASS 13.0 | 27-28-11-02 |
| ECLASS 14.0 | 27-28-11-02 |
