CLI C 1-3 GE/SW 8 MP - 1
Açıklamalar
General ordering data
Version CableLine, Conductor and cable markers, 2.5 - 5 mm, 3 x 4.2 mm, yellow
Order No. 0252611526
Type CLI C 1-3 GE/SW 8 MP
GTIN (EAN) 4008190020491
Qty. 200 pc(s).
Dimensions and weights
Depth 5 mm
Depth (inches) 0.197 inch
Height 3 mm
Height (inches) 0.118 inch
Width 4.2 mm
Width (inches) 0.165 inch
Net weight 0.052 g
Temperatures
Operating temperature range -30...80 °C
Environmental Product Compliance
RoHS Compliance Status Compliant without exemption
REACH SVHC No SVHC above 0.1 wt%
General data
Colour yellow
Colour of printing black
Halogen Yes
Insulation cross-section, max.
Material PVC, soft, without Cadmium
Material colour according to resistance code
Number of markers per combination 1 Component part = Conductor and cable markers
Number of markers per packaging unit
Form of supply Component part
Operating temperature range -30...80 °C
Operating temperature range, max. 80 °C
Operating temperature range, min. -30 °C
Orientation of print horizontal
Printed characters Numbers
Printing 8
Printing method hot-embossing
Recommended industries Process, Machinery
Type of printing Standard
UL 94 flammability rating V-0
Version MultiPack
Width 4.2 mm
Conductor and cable markers
Conductor O.D. 2.5 - 5 mm
Conductor O.D., max. 5 mm
Conductor O.D., min. 2.5 mm
Conductor cross-section, max. 4 mm²
Conductor cross-section, min. 1.5 mm²
Cross-section for connected wire 1.5 - 4 mm²
Halogen Yes
Downloads
Eplan Data Portal Eplan data
Product Change Notification
Catalogues Catalogues in PDF-format
Classifications
ETIM 6.0 EC001530
ETIM 7.0 EC001530
ETIM 8.0 EC001530
ETIM 9.0 EC001530
ECLASS 9.0 27-40-04-01
ECLASS 9.1 27-40-04-01
ECLASS 10.0 27-40-04-01
ECLASS 11.0 27-28-11-02
ECLASS 12.0 27-28-11-02
ECLASS 13.0 27-28-11-02
ECLASS 14.0 27-28-11-02
