General ordering data
| Version | D-SERIES, LED module, Rated control voltage: 110…230 V UC, Plug-in connection |
| Order No. | 7940018455 |
| Type | RIM 3 110/230VUC |
| GTIN (EAN) | 4032248878185 |
| Qty. | 10 pc(s). |
Dimensions and weights
| Depth | 32 mm |
| Depth (inches) | 1.26 inch |
| Height | 8.6 mm |
| Height (inches) | 0.339 inch |
| Width | 12.4 mm |
| Width (inches) | 0.488 inch |
| Net weight | 1 g |
Environmental Product Compliance
| RoHS Compliance Status | Compliant with exemption |
| RoHS Exemption (if applicable/known) | 7a, 7cI |
| REACH SVHC | Lead 7439-92-1 |
| SCIP | 2f8197d4-bb8c-4bf4-a0f8-f906b0694c85 |
Rated data UL
| Certificate No. (cURus) | E312083 |
Control side
| Rated control voltage | 110…230 V UC |
| Status indicator | Green LED |
General data
| Colour | black |
| UL94 flammability rating component | | Component | Housing | | UL94 flammability rating | V-2 | | |
Further details of approvals / standards
| Certificate No. (CSA) | 80107692 |
| Certificate No. (cURus) | E312083 |
Connection data
| Wire connection method | Plug-in connection |
