General ordering data
| Version | RIDERSERIES RCL, LED module, Rated control voltage: 110…230 V UC, Plug-in connection |
| Order No. | 8691030000 |
| Type | RIM 3 110/230VUC |
| GTIN (EAN) | 4032248361717 |
| Qty. | 10 pc(s). |
Dimensions and weights
| Depth | 34.5 mm |
| Depth (inches) | 1.358 inch |
| Height | 9 mm |
| Height (inches) | 0.354 inch |
| Width | 12.5 mm |
| Width (inches) | 0.492 inch |
| Net weight | 3.041 g |
Temperatures
| Storage temperature | -40 °C...70 °C |
| Operating temperature | -40 °C...70 °C |
| Humidity | 40 °C / 93 % rel. humidity, no condensation |
Environmental Product Compliance
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
Rated data UL
| Certificate No. (cURus) | E223759 |
Control side
| Rated control voltage | 110…230 V UC |
| Status indicator | red LED |
General data
Further details of approvals / standards
| Standards | UL508 |
| Certificate No. (cURus) | E223759 |
